How the bunker buster bomb works

B-2 stealth bomber

1

The GBU-57 bomb,

weighing 13,600kg (30,000lb),

is designed to destroy

underground targets

2

Once deployed from

high altitude, GPS

guidance system

locks onto target

3

The bomb relies on weight

and velocity to penetrate

hardened surfaces

4

Steel alloy

outer casing

is designed to

withstand

impact and

pressure

5

A ‘smart fuse’

times

detonation

based on

target depth

Up to 60 metres

(197ft) depth

varies depending

on ground

composition

Underground

target

B-2 stealth bomber

1

The GBU-57 bomb,

weighing 13,600kg

(30,000lb), is

designed to destroy

underground targets

2

Once deployed

from high altitude,

GPS guidance

system locks

onto target

3

The bomb relies on weight

and velocity to penetrate

hardened surfaces

4

Steel alloy outer casing

is designed to withstand

impact and pressure

5

Up to 60 metres

(197ft) depth

varies depending

on ground composition

A ‘smart fuse’ times

detonation based on

target depth

Underground

target
